An integrated circuit or monolithic integrated circuit also referred to as an IC , a chip , or a microchip is a set of electronic circuits on one small flat piece or "chip" of semiconductor material that is normally silicon. The integration of large numbers of tiny MOS transistors into a small chip results in circuits that are orders of magnitude smaller, faster, and less expensive than those constructed of discrete electronic components. The IC's mass production capability, reliability, and building-block approach to circuit design has ensured the rapid adoption of standardized ICs in place of designs using discrete transistors.
ICs are now used in virtually all electronic equipment and have revolutionized the world of electronics. Computers , mobile phones , and other digital home appliances are now inextricable parts of the structure of modern societies, made possible by the small size and low cost of ICs. Integrated circuits were made practical by technological advancements in metal—oxide—silicon MOS semiconductor device fabrication. These advances, roughly following Moore's law , make computer chips of today possess millions of times the capacity and thousands of times the speed of the computer chips of the early s.
Cost is low because the chips, with all their components, are printed as a unit by photolithography rather than being constructed one transistor at a time. Furthermore, packaged ICs use much less material than discrete circuits. Performance is high because the IC's components switch quickly and consume comparatively little power because of their small size and proximity.
The main disadvantage of ICs is the high cost to design them and fabricate the required photomasks. This high initial cost means ICs are only commercially viable when high production volumes are anticipated.
An integrated circuit is defined as: . A circuit in which all or some of the circuit elements are inseparably associated and electrically interconnected so that it is considered to be indivisible for the purposes of construction and commerce. Circuits meeting this definition can be constructed using many different technologies, including thin-film transistors , thick-film technologies , or hybrid integrated circuits.
However, in general usage integrated circuit has come to refer to the single-piece circuit construction originally known as a monolithic integrated circuit. Jacobi disclosed small and cheap hearing aids as typical industrial applications of his patent. An immediate commercial use of his patent has not been reported. The idea of an integrated circuit was conceived by Geoffrey Dummer — , a radar scientist working for the Royal Radar Establishment of the British Ministry of Defence.
Between and , Sidney Darlington and Yasuro Tarui Electrotechnical Laboratory proposed similar chip designs where several transistors could share a common active area, but there was no electrical isolation to separate them from each other.
The monolithic integrated circuit chip was enabled by the surface passivation process, which electrically stabilized silicon surfaces via thermal oxidation , making it possible to fabricate monolithic integrated circuit chips using silicon. The surface passivation process was developed by Mohamed M.
Atalla at Bell Labs in This was the basis for the planar process , developed by Jean Hoerni at Fairchild Semiconductor in early , which was critical to the invention of the monolithic integrated circuit chip.
Atalla's surface passivation process isolated individual diodes and transistors,  which was extended to independent transistors on a single piece of silicon by Kurt Lehovec at Sprague Electric in ,  and then independently by Robert Noyce at Fairchild later the same year. A precursor idea to the IC was to create small ceramic substrates so-called micromodules ,  each containing a single miniaturized component.
Components could then be integrated and wired into a bidimensional or tridimensional compact grid. This idea, which seemed very promising in , was proposed to the US Army by Jack Kilby [ citation needed ] and led to the short-lived Micromodule Program similar to 's Project Tinkertoy.
Newly employed by Texas Instruments , Kilby recorded his initial ideas concerning the integrated circuit in July , successfully demonstrating the first working example of an integrated circuit on 12 September Noyce's design was made of silicon , whereas Kilby's chip was made of germanium. Noyce's monolithic IC put all components on a chip of silicon and connected them with copper lines.
In turn, Hoerni's planar process was based on Mohamed Atalla's surface passivation process. Atalla and Dawon Kahng at Bell Labs in ,  made it possible to build high-density integrated circuits. MOS chips further increased in complexity at a rate predicted by Moore's law , leading to large-scale integration LSI with hundreds of transistors on a single MOS chip by the late s.
This led to the inventions of the microprocessor and the microcontroller by the early s. Advances in IC technology, primarily smaller features and larger chips, have allowed the number of MOS transistors in an integrated circuit to double every two years, a trend known as Moore's law. Moore originally stated it would double every year, but he went on to change the claim to every two years in In general, as the feature size shrinks, almost every aspect of an IC's operation improves.
The cost per transistor and the switching power consumption per transistor goes down, while the memory capacity and speed go up, through the relationships defined by Dennard scaling MOSFET scaling. Over the years, transistor sizes have decreased from 10s of microns in the early s to 10 nanometers in  with a corresponding million-fold increase in transistors per unit area.
The expected shrinking of feature sizes and the needed progress in related areas was forecast for many years by the International Technology Roadmap for Semiconductors ITRS. Initially, ICs were strictly electronic devices. The success of ICs has led to the integration of other technologies, in an attempt to obtain the same advantages of small size and low cost.
These technologies include mechanical devices, optics, and sensors. As of [update] , the vast majority of all transistors are MOSFETs fabricated in a single layer on one side of a chip of silicon in a flat two-dimensional planar process.
Researchers have produced prototypes of several promising alternatives, such as:. As it becomes more difficult to manufacture ever smaller transistors, companies are using multi-chip modules , three-dimensional integrated circuits , 3D NAND , package on package , and through-silicon vias to increase performance and reducing size, without having to reduce the size of the transistors.
The cost of designing and developing a complex integrated circuit is quite high, normally in the multiple tens of millions of dollars.
Modern semiconductor chips have billions of components, and are too complex to be designed by hand. Software tools to help the designer are essential. The tools work together in a design flow that engineers use to design and analyze entire semiconductor chips.
Integrated circuits can be classified into analog ,  digital  and mixed signal ,  consisting of both analog and digital signaling on the same IC. Digital integrated circuits can contain anywhere from one  to billions  of logic gates , flip-flops , multiplexers , and other circuits in a few square millimeters.
The small size of these circuits allows high speed, low power dissipation, and reduced manufacturing cost compared with board-level integration.
These digital ICs, typically microprocessors , DSPs , and microcontrollers , work using boolean algebra to process "one" and "zero" signals. Among the most advanced integrated circuits are the microprocessors or " cores ", which control everything from personal computers and cellular phones to digital microwave ovens.
Digital memory chips and application-specific integrated circuits ASICs are examples of other families of integrated circuits that are important to the modern information society. In the s, programmable logic devices were developed. These devices contain circuits whose logical function and connectivity can be programmed by the user, rather than being fixed by the integrated circuit manufacturer. This allows a single chip to be programmed to implement different LSI-type functions such as logic gates , adders and registers.
Programmability comes in at least four forms - devices that can be programmed only once , devices that can be erased and then re-programmed using UV light , devices that can be re programmed using flash memory , and field-programmable gate arrays FPGAs which can be programmed at any time, including during operation. Analog ICs, such as sensors , power management circuits , and operational amplifiers op-amps , work by processing continuous signals. They perform analog functions such as amplification , active filtering , demodulation , and mixing.
ICs can also combine analog and digital circuits on a single chip to create functions such as analog-to-digital converters and digital-to-analog converters. Such mixed-signal circuits offer smaller size and lower cost, but must carefully account for signal interference. Prior to the late s, radios could not be fabricated in the same low-cost CMOS processes as microprocessors. Modern electronic component distributors often further sub-categorize the huge variety of integrated circuits now available:.
The semiconductors of the periodic table of the chemical elements were identified as the most likely materials for a solid-state vacuum tube.
Starting with copper oxide , proceeding to germanium , then silicon , the materials were systematically studied in the s and s. Today, monocrystalline silicon is the main substrate used for ICs although some III-V compounds of the periodic table such as gallium arsenide are used for specialized applications like LEDs , lasers , solar cells and the highest-speed integrated circuits.
It took decades to perfect methods of creating crystals with minimal defects in semiconducting materials' crystal structure. The main process steps are supplemented by doping and cleaning. Mono-crystal silicon wafers are used in most applications or for special applications, other semiconductors such as gallium arsenide are used.
The wafer need not be entirely silicon. Photolithography is used to mark different areas of the substrate to be doped or to have polysilicon, insulators or metal typically aluminium or copper tracks deposited on them. Dopants are impurities intentionally introduced to a semiconductor to modulate its electronic properties.
Doping is the process of adding dopants to a semiconductor material. Since a CMOS device only draws current on the transition between logic states , CMOS devices consume much less current than bipolar junction transistor devices. A random-access memory is the most regular type of integrated circuit; the highest density devices are thus memories; but even a microprocessor will have memory on the chip.
See the regular array structure at the bottom of the first image. The layers of material are fabricated much like a photographic process, although light waves in the visible spectrum cannot be used to "expose" a layer of material, as they would be too large for the features. Thus photons of higher frequencies typically ultraviolet are used to create the patterns for each layer. Because each feature is so small, electron microscopes are essential tools for a process engineer who might be debugging a fabrication process.
Each device is tested before packaging using automated test equipment ATE , in a process known as wafer testing , or wafer probing. The wafer is then cut into rectangular blocks, each of which is called a die. Each good die plural dice , dies , or die is then connected into a package using aluminium or gold bond wires which are thermosonically bonded  to pads , usually found around the edge of the die.
Thermosonic bonding was first introduced by A. Coucoulas which provided a reliable means of forming these vital electrical connections to the outside world. After packaging, the devices go through final testing on the same or similar ATE used during wafer probing. Industrial CT scanning can also be used. This is known as Rock's law. Today, the most advanced processes employ the following techniques:. The earliest integrated circuits were packaged in ceramic flat packs , which continued to be used by the military for their reliability and small size for many years.
Commercial circuit packaging quickly moved to the dual in-line package DIP , first in ceramic and later in plastic. This package has "gull wing" leads protruding from the two long sides and a lead spacing of 0. In the late s, plastic quad flat pack PQFP and thin small-outline package TSOP packages became the most common for high pin count devices, though PGA packages are still used for high-end microprocessors.
Ball grid array BGA packages have existed since the s. Flip-chip Ball Grid Array packages, which allow for much higher pin count than other package types, were developed in the s. In an FCBGA package the die is mounted upside-down flipped and connects to the package balls via a package substrate that is similar to a printed-circuit board rather than by wires.
