US5665133A - Process for production of pure transparent quartz - Google Patents
Effective date : Year of fee payment : 4. Year of fee payment : 8. Year of fee payment : It is an object of the present invention to provide a quartz glass jig excellent in the plasma etching resistant characteristics, which does not generate an abnormal etching and particles when used for a plasma generating apparatus. Recently, for the surface treatment of a semiconductor element such as a silicon wafer, etc.
As the plasma etching method, there are a method of introducing a halogen-base corrosive gas such as a fluorine-base, a chlorine-base, etc. On the other hand, introducing a microwave via a microwave-introducing window to form the plasma of the above described halogen-base corrosive gas existing in the chamber, and treating a semiconductor element, a method for introducing a halogen-base corrosive gas and a microwave in a hanging bell-form quartz glass-made bell jar to form the plasma of the halogen-corrosive gas, and treating a semiconductor element for example depositing an insulating thin film on the surface of the semiconductor element is known.
In each treatment, an apparatus of generating plasma is used. Also, for the apparatus, quartz glass jigs are mostly used as a window material for introducing a microwave, a bell jar is used as a plasma-generating chamber and a ring for shielding the apparatus. As a material for these jigs natural quartz glass has been mainly used owing to the good electric characteristics and the high purity.
The surface of the jig, which is brought into contact with plasma, is roughened by mechanical working to stabilize the etching speed and prevent deposits from being released. For above-described roughening a grinding work using a grindstone with ceramic abrasive grains, diamond abrasive grains, silicon dioxide abrasive grains, etc.
The layer or microcrack portion is attacked by radicals formed in the plasma, consequently the microcrack portions only are etched to form abnormally large holes, and in the worst case, there is a fault that the breakage of the quartz glass jig starts from that portions. Also, recently, it has been confirmed that in the above-described plasma, together with the generation of the ions and radicals, abnormally intense ultraviolet rays and electron rays are emitted from the gas, and it has been found that these rays deteriorate the surface of the quartz glass jig, the deteriorated portions becomes the sources of generating particles, and the generated particles deposit on the surface of a semiconductor element to give secondary bad influences.
Furthermore, there is a problem that impurities sometimes enter the microcracks formed by the mechanical working method, and the impurities are volatized at the treatment of a semiconductor element to contaminate the semiconductor element. Also, natural quartz glass sometimes contains many bubbles and thus has the fault that even when the surface is roughened by a chemical method, which does not generate microcracks, the surface thereof is deteriorated by usually intense radiations and electron rays emitted in the plasma, when the bubbles are released and exposed on the surface, the deterioration greatly proceeds at the bubble portions to generate particles, which attach onto the surface of a semiconductor element to deteriorate particularly the dielectric breakdown characteristics.
The object of the invention is to provide a quartz glass jig excellent in the plasma etching resistant characteristics, which gives less abnormal etching and less deterioration of the surface of the quartz glass, and does not give contamination of semiconductor elements by the entrance of impurities.
Also, when the surface roughness Ra is less than 0. When the number of the microcracks of the surface of the jig exceeds the above-described range, the proceed of etching becomes faster by attacking by the radicals generated in the plasma, the microcracks become large, and in the worst case, the breakage of the quartz glass starts from that portion.
The number of the microcracks of the quartz glass surface can be measured by observing the microphotograph. Of course it is even better when no microcrack layer exists on the surface of the quartz glass jig of the invention. In addition to the above-described matters, in the quartz glass of the invention, it is better that the content of bubbles is 0 or 1 as the bubble classification by DIN. When the quartz glass contains bubbles exceeding the above-described range, the bubbles are eroded by the radicals and the ions generated in the plasma and released to become precursors of abnormal holes, and the deterioration further proceeds by the abnormally intense radiations and electron rays in succession thereof to form large holes and generate particles.
The term that the content of bubbles is 0 or 1 as the bubble classification by DIN described above is that according to DIN Deutsche Industrie Norm , the total cross sections cm  2 of the bubbles existing in cm 3 are from 0 to 0. Also, when the double refraction amount of the quartz glass exceeds the above-described range, the increase of the density of the quartz glass proceeds by the abnormally intense ultraviolet rays and electron rays irradiated to the twisted portion and microcracks become large.
By establishing the fictive temperature to the above-described range, the density of the quartz glass is lowered to relax the structure, by the irradiation of the abnormally intense ultraviolet rays and electron rays, defects are hard to generate and the increase of the density can be prevented.
In the quartz glass jig of the invention, a fine roughness is formed on the surface as described above, which largely acts on the transmittance of ultraviolet rays. When the transmittance is small, the quartz glass surface is deteriorated by ultraviolet rays. Particularly, The Si-O bond of the quartz glass is broken by abnormally intense ultraviolet rays and electron rays simultaneously generating with the radicals and the ions in the plasma to form a defect, the density becomes high, microcracks become large, the etching speed is greatly accelerated, and large holes are formed.
The above-described inner transmittance means the transmittance, which does not contain the reflection loss at the outer surface of the quartz glass, and the transmittance containing the reflection loss is called an apparent transmittance. As the quartz glass, wherein the bubble classification by DIN is 0 or 1 and the double refraction amount is in the above-described range, there is suitably a synthetic quartz glass obtained by hydrolyzing a silicon compound in the vapor phase.
The measurement of the fictive temperature is by a laser Raman method. The quartz glass jig of the invention is prepared by a natural or synthetic quartz glass as described above, and a synthetic quartz glass, which has less content of bubbles and can be easily obtained as a quartz glass having a high homogeneity, is particularly preferred.
Then, the invention is explained in detail by the practical examples but the examples are shown for illustration and the invention is not limited to those examples.
As shown in FIG. In this case, 10, silicon wafers were treated but an abnormal increase of particles was not confirmed. By carrying out the frost-treatment by the same method as Example 1 except that a natural quartz glass wherein the bubble classification by DIN was 2 was immersed in the frost-treatment liquid used in Example 1, a window material was prepared.
When the etching treatment of Si wafers as in Example 1 was carried out, at the case of treating Si wafers, an abnormal generation of particles was confirmed. The surface of a natural quartz glass wherein the bubble classification by DIN was 2 was subjected to a sand-blast with SiC particles of In the quartz glass obtained, the existence of a microcrack layer was confirmed. A quartz glass window material was prepared using the quartz glass and when the etching treatment of Si wafers was carried out as in Example 1, from the first, particles were generated and the etching treatment could not be carried out.
The synthetic quartz glass was subjected to a hydrogen doping treatment. Then, by applying the frost treatment as in Example 1, a synthetic quartz glass having the surface roughness Ra of 0. When silicon wafers were treated, an abnormal increase of particles was not confirmed. When silicon wafers were treated, an abnormal increase of particles was confirmed. The plasma resistant quartz glass jig described in one of the preceeding claims 1 to 4 , wherein the quartz glass is a synthetic quartz glass obtained by hydrolyzing a silicon compound in the vapor phase.
USB2 en. EPB1 en. KRB1 en. DET2 en. SGA1 en. TWIB en. Optical member made of high-purity and transparent synthetic silica glass and method for production thereof or blank thereof. Moulding having a high content of silicon dioxide, and process for the production of such mouldings.
Cvd jig, manufacture of semiconductor device using the same, and manufacture of the cvd jig. Quartz glass having irregularities on the surface and method for producing the same. Quartz glass member for dry etching and dry etching apparatus equipped with the same. Quartz glass jig having large irregularities on the surface and manufacturing method thereof. EPA2 en. EPA3 en.
DED1 en. KRA en. USA en. CNB en. DET3 en. Method for improving thickness uniformity of deposited ozone-TEOS silicate glass layers.
Enclosure for the treatment, and particularly for the etching of substrates by the reactive plasma method. USB1 en. Methods for protecting silicon or silicon carbide electrode surfaces from morphological modification during plasma etch processing. Apparatus and method for reactive atom plasma processing for material deposition. EPA1 en. Method and apparatus for protection of conductive surfaces in a plasma processing reactor.
